Comtech EF Data CDM-710 Installation And Operation Manual page 224

CDM-710 Satellite Modulator
Remote Control
Command
Parameter (Instruction for Command
Type Code and
Qualifier)
Rx Link N/A 4 bytes
Margin
ASI Rx Frame ARF= 2 bytes
Size
ASI Tx Frame ATF= 2 bytes
Size
Clear All CAE= None
Stored Events
Circuit ID CID= 24 bytes
String
Arguments
Description of Arguments
or Response
to Query
Query only.
Unit returns the value of the Link Margin.
Returns 00.0 if demod is unlocked.
Example LNK=12.3
Indicates whether the ASI Rx Frame Size is 188 or 204 bytes
(ASI card only), in the form: sf
Where:
s = interface slot ( 1 or 2 )
f = frame size
0 = 188 bytes
1 = 204 bytes
Example: ARF=11 ( sets interface slot 1 to 204 byte frame size)
Indicates whether the ASI Tx Frame Size is 188 or 204 bytes
(ASI card only), in the form: sf
Where:
s = interface slot ( 1 or 2 )
f = frame size
0 = 188 bytes
1 = 204 bytes
Example: ATF=11 ( sets interface slot 1 to 204 byte frame size)
Forces the software to clear the software events log.
Example: CAE=
Note: This command takes no arguments
Sets or queries the user-defined Circuit ID string, which is a fixed
length of 24 characters.
Valid characters include:
Space ( ) * + – , . / 0 9 and A thru Z
Response
to
Command
N/A
ARF=
ARF?
ARF*
ARF#
ATF=
ATF?
ATF*
ATF#
CAE=
CAE?
CAE*
CAE#
CID=
CID?
CID*
CID#
A–63
Revision 9
MN/CDM710.IOM
Query
(Instruction
Response to Query
Code and
Qualifier)
LNK? LNK=xxxx
ARF?s ARF=sf
ATF?s ATF=sf
N/A N/A
CID? CID=xxxxxxxxxxxxxxxx
xxxxxxxx
