If the CDM-Qx/QxL is to be mounted in a rack, ensure that there is adequate clearance for
ventilation, particularly at the sides. In rack systems where there is high heat dissipation, forced
air cooling must be provided by top or bottom mounted fans or blowers. Under no circumstance
should the highest internal rack temperature be allowed to exceed 50°C (122°F).

2.2.1 Method A: Optional Rear-Mounting Support Brackets

Install optional rear-mounting support brackets using mounting kit KT/6228-2:
Quantity
2
4
2
2
2
4
The tools required for this installation are a medium Phillips™ screwdriver and a 5/32-inch
SAE Allen™ Wrench. The kit is installed as illustrated in Figure 2-1 via the following
procedure:
Step
Secure the #10 shoulder screws to the unit chassis through the rear right and left
1 side mounting slots, using the #10 flat washers, #10 split washers, and #10 hex
nuts as shown.
Install the rear support brackets onto the equipment rack threaded rear mounting
2
rails, using the #10 rack bracket bolts.
Mount the unit into the equipment rack, ensuring that the shoulders of the #10
3
shoulder screws properly engage into the rear support bracket slots.
Part Number
HW/10-32SHLDR
HW/10-32FLT
HW/10-32SPLIT
HW/10-32HEXNUT
FP/6138-1
HW/10-32x1/2RK
Description
Screw, #10 Shoulder
Washer, #10 Flat
Washer, #10 Split
Nut, #10 Hex
Bracket, Rear Support
Bolt, #10 Rack Bracket
