Chapter 4: Commands for CLI configuration
switchport vlan mapping
Command:
switchport vlan mapping <group id : 1-29>
switchport
vlan VLAN commands
mapping Maps an interface to a VLAN translation group.
<group id : 1-29>
Default:
None
Usage Guide:
To configure Group mapping Table for specific interface
Example:
To configure Group mapping (Group 25) for GigabitEthernet X/X
Switch# configure terminal
Switch (config)# interface GigabitEthernet X/X
Switch (config-if) # switchport vlan mapping 25
switchport vlan protocol group
Command:
switchport vlan protocol group <word16> vlan <vlan_id>
switchport
vlan VLAN commands
protocol Protocol-based VLAN commands
group Protocol-based VLAN group commands
<word16> Group Name (Range: 1 - 16 characters)
vlan vlan keyword
<vlan_id> VLAN ID required for the group to VLAN mapping (Range: 1-4095)
Default:
None
Usage Guide:
To configure VLAN protocol group for specific interface
Example:
To configure VLAN protocol group as tabled below for GigabitEthernet X/X
Switch# configure terminal
Switch (config)# interface GigabitEthernet X/X
Switch (config-if) # switchport vlan protocol group 8081 vlan 5
switchport voice vlan discovery-protocol
Command:
switchport voice vlan discovery-protocol both | lldp | oui
switchport
106
Switching mode characteristics
Group id
Switching mode characteristics
Switching mode characteristics
