HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
6.19.2 4-Port 10GBase LAN/WAN-XFP Line Processing Unit
S(LPUS-41)
Overview
Figure 6-161
Unit S. 1588v2 and HQoS are not supported on this board.
Figure 6-161 Appearance of the 4-port 10GBase LAN/WAN-XFP Line Processing Unit S
Panel
Figure
Processing Unit S.
Figure 6-162 Panel appearance of the 4-port 10GBase LAN/WAN-XFP Line Processing Unit S
Table 6-450 Indicators on the panel of the 4-port 10GBase LAN/WAN-XFP Line Processing Unit
S
Component
OFL button
OFL indicator
(red)
RUN (green)
Issue 01 (2012-09-30)
The right-most two ports are numbered in the format of "slot number/0/port number" and the left-most
two ports are numbered in the format of "slot number/1/port number".
shows the appearance of the 4-port 10GBase LAN/WAN-XFP Line Processing
6-162shows the panel appearance of the 4-port 10GBase LAN/WAN-XFP Line
Table 6-450
Description
It is an OFL button. Before removing a board, press the OFL button.
Hold the button for five seconds till the OFL indicator is on. Then, the
board can be pulled out.
If the indicator is steady on, it indicates that you can remove the
board.
If the indicator blinks once every 2s (0.5 Hz), it indicates that the
system is running normally. If the indicator blinks twice every 1s (2
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
describes the indicators on the panel.
6 Boards
463
