Controller-to-Target
Parameter
Instruction Code and
Type
Qualifier
(* indicates
End-of-Life)
Command Query
Time Protocol TPE= TPE?
Enable
Time Protocol TPS= TPS?
Server
Terminal Status N/A TSC?
Change
Serial Interface Operation
Arguments
for Command
(Note that all arguments are ASCII numeric codes from 48 to 57)
or Query
1 byte, Command or Query.
numerical Sets or returns Time Protocol in the form x, where:
0=Disable
1=Enable
COMMAND EXAMPLE: <0001/TPE=1{CR} (Enables Time protocol)
15 bytes, Command or Query.
alphanumeric Sets or returns the Time Server IP Address for the unit's Tx Ethernet management
port, in the form xxx.xxx.xxx.xxx.
Default value: 255.255.255.255
COMMAND EXAMPLE: <0001/TPS=192.168.001.005{CR}
1 byte Query only.
Indicates if there has been a change in the configuration since the last time the
command was given, in the form x, where:
0=No status change.
1=Status change has occurred.
NOTES:
1) A "status change" is defined as any time a parameter is changed, e.g.,
when a command is successfully executed that changes a value. A status
change also results when there is a fault condition.
2) A query does not set the status change flag. The status change flag is
cleared after being read.
EXAMPLE: <0001/TSC?{CR}
>0001/TSC=0{CR}{LF}
Low Power Outdoor (LPOD) Amplifier/Block Up Converter (BUC)
Description of Arguments
5–41
Revision 15
Target-to-Controller
(see Description of
Arguments)
Response to Response
Command to Query
TPE= TPE=x
TPE?
TPS= TPS=xx.xx
x.xxx.xxx
TPS?
TSC= TSC=x
