3.2.2 General-purpose registers

General-purpose registers are mapped at particular addresses (FEE0H to FEFFH) of the data memory. The
general-purpose registers consists of 4 banks, each bank consisting of eight 8-bit registers (X, A, C, B, E, D, L, and H).
Each register can be used as an 8-bit register, and two 8-bit registers can also be used in a pair as a 16-bit register
(AX, BC, DE, and HL).
These registers can be described in terms of function names (X, A, C, B, E, D, L, H, AX, BC, DE, and HL) and
absolute names (R0 to R7 and RP0 to RP3).
Register banks to be used for instruction execution are set by the CPU control instruction (SEL RBn). Because of
the 4-register bank configuration, an efficient program can be created by switching between a register for normal
processing and a register for interrupts for each bank.
FEFFH
BANK0
FEF8H
BANK1
FEF0H
BANK2
FEE8H
BANK3
FEE0H
FEFFH
BANK0
FEF8H
BANK1
FEF0H
BANK2
FEE8H
BANK3
FEE0H
62
CHAPTER 3 CPU ARCHITECTURE
Figure 3-16. Configuration of General-Purpose Registers
(a) Absolute name
15
(b) Function name
15
Preliminary User's Manual U16315EJ1V0UD
16-bit processing
RP3
RP2
RP1
RP0
0
16-bit processing
HL
DE
BC
AX
0
8-bit processing
R7
R6
R5
R4
R3
R2
R1
R0
7
0
8-bit processing
H
L
D
E
B
C
A
X
7
0
