98 Appendix A

Physical Specifications

The Silicon Graphics 320 visual workstation measures approximately
9" wide by 17" high by 17" deep. Removable media drives are at the
front top of the enclosure for easy access in desktop or deskside
arrangements. Slots for PCI options, disk drives, memory modules,
and processor modules are accessible by removing the side cover.
Cooling is achieved by two internal fans plus a fan in the power
supply.

Environmental Range Specifications

Table A-1 Environmental Range Specifications
Condition
Operating Temperature
Operating Relative Humidity
Operating Altitude
Operating 3-Axis SineVibration
Operating Half Sine Shock
Operating Random Vibration
Non-Operating Temperature
Non-Operating Relative Humidity 5% to 95%
Non-Operating Altitude
Non-Operating 3-Axis Sine
Range
10º C to 35º C
10% to 85%
Sea-level to 10,000 feet
0.02 inches displacement, 5 to 19 Hz
0.2 G, 20 to 200 Hz
5 G, 15 mS Horizontal Plane
7.5 G, 10 mS Vertical Plan
10 to 200 Hz, 0.0005 G(Square)/Hz
3 to 10 Hz, 5 dB/Octave
200 to 500 Hz, –5 dB/Octave
0.41 G (RMS) Overall
-40ºC to 85ºC
Sea level to 40,000 feet
0.1 inches displacement, 5 to 19 Hz
