20 Chapter 2

Replacing the Covers

To replace the front and side covers, see the following instructions.

Replacing the Front Cover

1. Place the tabs on the bottom of the cover into the notches on the
lower edge of the chassis.
2. Tilt the cover up and press until it snaps into place.
3. Close the sliding front panel by pulling up on the tab.
Figure 2-4 Replacing the Front Cover
