34 Chapter 4
5. Locate two drive sleds—one to attach to each side of the drive.
If you are replacing a drive, remove the old drive, then
remove the sleds from the drive.
For detailed instructions, see "Removing a Removable Media
Drive" on page 38.
If you are not replacing a drive, remove two sleds from the
side panel, as shown in Figure 4-2. Also remove the spare
screws from the lower right edge of the side panel.
Removing the Sleds from the Side Panel
Figure 4-2
Spare drive sleds
Spare screws
