60 Chapter 5
Installing the Display Option Card
If you ordered a flat panel display monitor when you purchased your
Silicon Graphics 320 visual workstation, the option card is
preinstalled. You do not need to install it. If you ordered the Silicon
Graphics 1600SW flat panel monitor separately from the workstation,
you need to install the option card before attaching the monitor.
1.
Shut down the system and turn off the power. For detailed
instructions, see "Shutting Down the System" on page 12.
2.
Unplug the power cord from the back of the system.
3.
Remove the side cover. For detailed instructions, see "Removing
the Side Cover" on page 16.
4.
Remove the cover plate from the display option slot on the back
of the system, as shown in Figure 5-5.
Reach inside the system and hold the back of the cover plate
with your hand as you remove the two screws.
Pull out the cover plate.
Save the cover plate. In the future, if you remove the option
card and leave the slot empty, you will need to reinstall the
cover plate.
Removing the Display Option Slot Cover Plate
Figure 5-5
