Physical Environment Specifications; Table B-1 Physical Environment Specifications - Silicon Graphics 230 User Manual

B.
007-4263-001
Appendix B
Physical Environment Specifications
Table B-1 shows the physical environment specifications for the Silicon Graphics 230
Visual Workstation.
Table B-1 Physical Environment Specifications
System dimensions 48.9 cm (19.25'') H x 20.95 cm (8.25'') W x 44.1 cm (17.375'')
D-without bezel, 49.16 cm (19.375'') D-with bezel
Power Requirements The power requirements are shown on the back of the system
Ambient Temperature +10°C (+50°F) to +35°C (+95°F) (operating)
-20°C (-4°F) to +60°C (+149°F) (non-operating)
Relative Humidity 10% to 90% non-operating (no condensation)
Vibration 0.38 mm (0.015''), 5-16.2 Hz; 0.2 G, 16.2-250 Hz (operating)
0.6 G, 5-27.1 Hz; 0.4 mm (0.016"), 27.1-50 Hz; 2 G, 50-500 Hz
(non-operating)
121
