Figure 4-11 Removing The Internal Hard Drive Bracket - Silicon Graphics 320 Owner's Manual

5. Remove the drive bracket from the system, as shown in
Figure 4-11.
Caution: Space is tight, so avoid contact with the DIMMs
while installing the bracket.
Remove the two screws.
Carefully pull the bracket to the left and then out.

Figure 4-11 Removing the Internal Hard Drive Bracket

6. If you are replacing a drive, remove the old drive from the
bracket. For detailed instructions, see "Removing an Internal
Hard Drive" on page 46.
Internal Drives 41
