A: Technical Specifications and Pinouts
Physical and Environmental Specifications
154
Table A-1 shows the physical and environmental specifications for the deskside system.
Table A-1
Physical Environment Specifications
Feature
Deskside system
dimensions
Weight
Power requirements
Voltage and frequency
Temperature Tolerance
(operating)
Temperature tolerance
(non-operating)
Relative humidity
Heat dissipation
Maximum altitude
Vibration, sine sweep
(operating)
Vibration, sine sweep
(non-operating)
Vibration, random
(operating)
Specification
13.5 in. (34.3 cm) tall
16.1 in. (40.1 cm) wide
21.4 in. (54.4 cm) deep
Note: The rear fan assembly extends an additional 1.25 inches (3 cm)
from the rear of the enclosure. You must leave adequate clearance for
airflow at the rear of the enclosure.
Approximately 60 lb. (27.2 kg)
50-60 Hz and 100-120/200-240 VAC
100-240 VAC, 50-60 Hz, (750 W max)
+5
o
C (41
o
F) to +35
o
C (95
+5
o
C (41
o
F) to +30
o
C (86
-40
o
C (-40
o
F) to +85
o
C (185
10% to 80% operating (no condensation)
10% to 95% non-operating (no condensation)
2,560 Btu/h maximum (750 W)
10,000 ft (3,049 m) operating
40,000 ft (12,195 m) non-operating
5-500-5 Hz, 0.25 G input
3-200-3 Hz, 0.5 G input
0.582 Grms (5-300Hz) for 15 minutes each axis
May vary based on internal options
o
F) 5000 ft ASL or less
o
F) 5000 ft ASL to 10,000 ft ASL
o
F)
007-4772-002
