5. Install the option card.
Caution: Space is tight, so avoid contact with the DIMMs
while installing the card.
Position the board so the connector on the bottom faces the
port on the system board and the connector on the edge faces
the opening in the back panel (see Figure 5-6).
Align the connectors and press the board into the connector
until it snaps into place.
Figure 5-6 Installing the Display Option Card
Option Cards 61
