Figure 4-13 Installing The Internal Hard Drive Bracket - Silicon Graphics 320 Owner's Manual

11. Install the bracket in the drive slot, as shown in Figure 4-13.
Space is tight, so avoid contact with the DIMMs
Caution:
while installing the bracket.
Position the drive bracket behind the drive slot.
Push the bracket up so the tabs on the top of the bracket align
with the openings in the drive slot. Slide the bracket towards
the front of the system until it stops.
Insert and tighten the two screws.

Figure 4-13 Installing the Internal Hard Drive Bracket

Internal Drives 43
