Figure 4-16 Removing The Internal Hard Drive Bracket - Silicon Graphics 320 Owner's Manual

5. Remove the drive bracket from the system, as shown in
Figure 4-16.
Space is tight, so avoid contact with the DIMMs
Caution:
while removing the bracket.
Remove the two screws.
Carefully pull the bracket to the left and remove it.

Figure 4-16 Removing the Internal Hard Drive Bracket

Internal Drives 47
