Figure 5-3 Removing A Pci Card - Silicon Graphics 320 Owner's Manual

58 Chapter 5
5. Remove the card, as shown in Figure 5-3.
Insert a Philips screwdriver into the opening opposite the
screw and remove the screw.
Grasp the card and gently pull it out of the slot.
If you are removing a SCSI PCI card and have external devices
attached, disconnect the device cable from the external connector.
If internal SCSI hard drives are attached, see "Disconnecting the
SCSI PCI Option Card Internal Cable" for information on
disconnecting the cable from the internal drives and card.
Removing a PCI Card
Figure 5-3
