Figure 5-1 Removing The Cover Plate From A Pci Card Slot - Silicon Graphics 320 Owner's Manual

5. If there is a blank plate covering the PCI slot opening, remove it,
as shown in Figure 5-1.
Insert a Philips screwdriver into the opening opposite the
screw and remove the screw.
Pull out the plate.
Save the plate. In the future, if you remove the PCI card and leave
the slot empty, you will need to reinstall the plate.
Removing the Cover Plate from a PCI Card Slot
Figure 5-1
Option Cards 55
