Inside patient area:
1. Dental unit
2. Planmeca monitor
3. Planmeca ProX X-ray tube head and arm
assembly
4. Planmeca ProSensor control box
5. Planmeca operating light
6. Foot control. Use only IEC 60601-1 approved
power source supplied by Planmeca
7. Tablet
8. Planmeca intraoral scanner
User's manual
Outside patient area:
9. Foot control battery charger
10. Planmeca ProSensor PoE port and power
cable
11. External PC
12. Planmeca ProX generator assembly
