Macro on/off
Freezing/unfreezing image
User's manual
When the intraoral camera turns on,
•
the indicator light on the handpiece turns blue,
•
you will hear a short sound signal,
•
the Planmeca Romexis intraoral camera view is displayed on the
monitor,
•
the text "Intraoral camera active" is displayed on the dental unit's control
panel.
Once the intraoral camera is activated, you can operate it
•
from the dental unit's foot control, if the camera has been turned on by
picking it up from the instrument console
•
from the camera handpiece, or
•
remotely from the Planmeca Romexis user interface.
You can use the camera in normal or macro mode, as well as freeze and
save the image. The LED on the handpiece is turned on and off
simultaneously with the intraoral camera.
A short sound signal indicates that the macro mode is turned on/off. When
the macro mode is on, autofocus is off and the indicator light on the
handpiece is lilac.
Interface
Action
Handpiece
Press the Power/macro button to turn the macro
mode on/off.
A short sound signal indicates the freeze/unfreeze of an image. When the
image is frozen, the indicator light on the handpiece is green. When you
unfreeze the image, the camera goes back to live stream (indicated by the
blue indicator light on the handpiece).
Interface
Action
Foot control
In Planmeca Compact i dental units, push the foot
control pedal to the left or right to freeze/unfreeze the
image.
Handpiece
There are two ways to freeze/unfreeze the image
from the handpiece.
•
•
Planmeca Romexis
Press the Freeze button to freeze the image. Press
the Resume button to unfreeze the image. The
buttons are located at the bottom of the intraoral
camera window.
Press the Image control button halfway and hold
it to freeze the image. When you release the
button, the image unfreezes.
Press the Image control button all the way down
and release it to freeze the image. To unfreeze
the frozen image, either press the Image control
button halfway and then release it, or press the
button all the way down and release it.
23 Operating instruments
Planmeca Compact i
165
