Timer; Door Open / Assistant Call - Planmeca Compact i Touch v2 User Manual

22.4 Timer

About this task
Steps
Results

22.5 Door open / assistant call

User's manual
Foot control: When all the instruments are in their holders you can fill the cup
either by briefly pushing the pedal down twice or by pushing down the pedal
once until the filling starts (0,5 - 1 sec.). The unit will automatically fill the cup
and then rinse the bowl. Cup filling stops automatically after a preset time.
Cup filling can be stopped before it stops automatically by pushing the pedal
briefly down.
If the pedal is pushed for longer than 1 second, water flows for as long as
the pedal is pushed, and the bowl is not rinsed.
The flow rate of the cup fill can be adjusted by turning the black knob inside
the unit, see section "Adjusting cup fill and bowl rinse flow rates" on page
187.
The duration of the cup fill can be programmed, see section "Duration of cup
filling" on page 189.
The timer memory contains six preprogrammed time settings. Follow the
steps below to activate a timer.
NOTE
Other functionalities can be used while the timer is running.
NOTE
The timer can not be run from the foot control.
1. Press Timer to open a list of available timers.
2. Select a timer from the list.
The Timer button's indicator light is lit and the duration of the timer is
displayed on the control panel.The countdown begins immediately, but
the selected time is displayed for five seconds before the actual
countdown is displayed.
If you wish to close the list without selecting a timer, press Close.
When the timer reaches zero you will hear two signal tones and the indicator
light goes off.
The function can be cancelled by pressing Timer again.
The preset timers can be reprogrammed, see section "Timer settings" on
page 187.
If you have installed a door opening device or assistant call, you may
activate these from the control panel or the foot control.
22 Operating dental unit
Planmeca Compact i 113
