22 Operating dental unit
How to capture image
Interface
Planmeca dental unit:
Control panel on Flexy-
holder
Planmeca dental unit: Foot
control
Planmeca Solanna Vision
Planmeca Romexis

22.8 X-ray film viewer

130 Planmeca Compact i
Action
Planmeca Compact i: The dental unit can be configured so that an
image is captured when you press the Flexy button, contact your
Planmeca dealer.
Planmeca Compact i: The dental unit can be configured so that an
image is captured when you push one of the side knobs on the foot
control, contact your Planmeca dealer.
Solanna Vision window is open on the dental unit's control
When the
panel, press the handle button to capture an image. You will hear a
clicking sound when you press the button.
In the
clicking Still camera.
Solanna Vision window is open, press the Enter or p key
When the
on the Planmeca Romexis keyboard to capture an image.
The control panel display can be used for viewing X-ray films. To open the
viewer, press X-ray film viewer.
When the display is used as an X-ray film viewer, its intensity is increased to
the maximum value.
CAUTION
The X-ray film viewer is suited for X-ray films with an optical density of ≤1.2
OD. It is not a tool for diagnosis.
When you want to close the X-ray film viewer, press OK.
Solanna Vision window, capture an image by
