User's manual
General error messages
ERROR EXPLANATION
CODE
E1.04 Cup filling valve short circuit.
Disconnect valve and check if error disappears.
E1.05 Water flush valve short circuit.
Disconnect valve and check if error disappears.
E1.06 Separator pulse valve short circuit.
Disconnect valve and check if error disappears.
E1.07 Ejector valve short circuit.
Disconnect valve and check if error disappears.
E1.08 Extra out 1 short circuit.
Disconnect output and check if error disappears.
E1.09 Extra out 2 short circuit.
Disconnect output and check if error disappears.
E1.10 Extra out 3 short circuit.
Disconnect output and check if error disappears.
E1.11 Separator start signal / Microvac's start valve short circuit.
E1.12 Assistant syringe water valve short circuit.
Disconnect valve and check if error disappears.
E1.13 Separator alarm reset signal short circuit.
Disconnect output and check if error disappears.
E1.14 PLANET output (ELMP) short circuit.
Disconnect output and check if error disappears.
E2.01 Incoming water valve open circuit.
Error can be detected when circuit is dead.
E2.02 Incoming air valve open circuit.
Error can be detected when circuit is dead.
E2.03 Bowl rinse valve open circuit.
Error can be detected when circuit is dead.
E2.04 Cup filling valve open circuit.
Error can be detected when circuit is dead.
E2.05 Main Control PCB output open circuit warning.
E2.06 Separator pulse valve open circuit.
Error can be detected when circuit is dead.
E2.07 Main Control PCB output open circuit warning.
E2.08 Main Control PCB output open circuit warning.
E2.09 Main Control PCB output open circuit warning.
E2.10 Main Control PCB output open circuit warning.
E2.11 Separator start signal open circuit / Microvac valve open
circuit.
31 Help and error messages
Planmeca Compact i 265
