Planmeca Compact i Touch v2 User Manual page 299

User's manual
Humidity:
Quality:
Oil contamination:
Particulate
contamination:
Connection:
Water and air filters
Water filter:
Air filter:
Replacement of water and air filters should be performed by qualified
service technician according to the maintenance schedule.
See section "Annual maintenance" on page 6.
Suction connection
Vacuum:
Flow rate:
Connection:
Type:
Class:
Drain connection
Capacity:
Connection:
Water and air quick-connectors (optional)
Output pressure:
Foot control power supply (optional)
Type:
Wireless foot control (optional)
Battery size:
Battery type:
Planmeca ProSensor power supply (optional)
Phihong Single Port Injector
Type:
Input voltage:
Output voltage:
Max. output current:
Insulation voltage
Primary-secondary
dew point not greater than −20 °C at atmospheric
pressure
medical grade, dry and oil-free
3
max. 0.5 mg/m
≤ 100 particles per cubic meter for 1 μm to 5 μm
particle size
1/4"
25 µm (internal), 5 µm (external suggested)
25 µm (internal)
≥ 150 mbar
≥ 550 l/ min
Ø 50 / 46 mm
Medium volume
Wet or dry depending on installed options
min. 10 l/min
Ø 50 / 46 mm
water 2.8 bar, air 5.5 bar (regulated internal water
and air pressure
MENB1010A0903F01
AA, HR6
NiMH 1.2V, min 2000mAh, low self-discharge,
UL-listed (USA, Canada only)
PSA16U-480 (POE)
100-240 VAC (50-60 Hz)
48VDC
0.35 A
3000VDC
34 Technical information
Planmeca Compact i 289
