8.1.3 Side delivery with hanging-tube instruments
1. Monitor
2. Chair-mounted left-right suction arm with
Flexy-holder
3. Side delivery arm
4. Instrument console with hanging-tube (HT)
instruments
5. Control panel
6. Tray
User's manual
8 Planmeca Compact i dental unit
7. Patient chair
8. Bowl
9. Bowl rinse tube
10. Cup fill tube
11. Operating light
Planmeca Compact i
19
