8 Planmeca Compact i dental unit
8.1.2 Over-the-patient delivery with hanging-tube instruments
1. Monitor
2. Cup fill tube
3. Bowl rinse tube
4. Bowl
5. Chair-mounted left-right suction arm with
Flexy-holder
6. Patient chair
18
Planmeca Compact i
7. Control panel
8. Instrument console with hanging-tube (HT)
instruments
9. Tray
10. OP delivery arm
11. Operating light
User's manual
