14.3 Foot control functions

14.3.1 Centre knob functions

Action
Centre knob left
Centre knob left, long activation
Centre knob right
Centre knob right, long activation
Centre knob up
Centre knob up, long activation
Centre knob down
Centre knob down, long activation

14.3.2 Left-side and right-side knob functions

Action
Left-side knob up
Left-side knob down
Right-side knob up
Right-side knob down

14.3.3 Pedal functions

Action
Pedal left
Pedal down, short activation
Pedal down, long activation
Pedal right & down
User's manual
NOTE
When the motorised headrest is activated, the centre knob activates other
features than those presented below. For more information, see section
"Operating motorised headrest" on page 107.
Function
Chair to automatic position A
Backrest down
Chair to automatic position B
Backrest up
Chair to automatic position C
Chair up
Chair to automatic position D
Chair down
Function
Can be configured by a Planmeca service technician.
Default function: Operating light on/off
Can be configured for a selection of instruments by a
Planmeca service technician.
The function depends on the selected instrument slot.
Only one function per instrument slot can be
configured.
Can be configured by a Planmeca service technician.
Default function: Intraoral camera on/off
Chair to rinsing position.
The factory default functions of the foot control pedal when the dental unit is
equipped with a standard pedal and no instrument is activated are presented
below.
Function
Assistant call
Cup fill and bowl rinse
Cup fill for as long as the pedal is pressed
Chair to rinsing position
When an instrument is activated, the functions of the standard pedal depend
on the used instrument. These instrument-specific functions are presented
below.
14 Foot control
Planmeca Compact i 77
