34 Technical information

34.1 Technical specifications

User's manual
Original manufacturer
PLANMECA Oy, Asentajankatu 6, 00880 Helsinki, FINLAND
Phone: +358 20 7795 500, fax: +358 20 7795 555, www.planmeca.com
Colours
Painted parts:
Upholstery colours:
Mechanical dimensions
Installed:
Weight
150 kg (331 lbs)
Maximum allowed load on patient seat
Maximum allowed patient weight 185 kg (407 lbs) and accessories load of
15 kg (33 lbs)
Environmental conditions
Transportation conditions
Temperatures:
Relative humidity:
Air pressure:
Storage conditions
Temperatures:
Relative humidity:
Air pressure:
If the unit has been stored at temperatures below +10 °C (+50 °F) for more
than a few hours, time must be allowed for the unit to reach room
temperature in the original packing before connecting the unit to the mains
voltage.
Operating conditions
Temperatures:
Relative humidity:
Air pressure:
Altitude:
Mains voltage and frequency
Mains voltage setting:
Mains frequency:
Fuse rating and type
RAL-9016
Please consult your dealer for availability
(H x D x W) 1210 mm x 963 mm x 1990 mm
(see template for details)
-20°C to +60°C (-4°F to +140°F)
5% RH to 95% RH; non-condensing humidity
700 hPa to 1060 hPa (10 psi to 15 psi)
-5°C to +60°C (+23°F to +140°F)
5% RH to 95% RH; non-condensing humidity
700 hPa to 1060 hPa (10 psi to 15 psi)
+15°C to +35°C (+59°F to +95°F)
5% RH to 95% RH; non-condensing humidity
800 hPa to 1060 hPa (12 psi to 15 psi)
< 2000 m (less than 1.25 miles)
100V~
115V~
220-240V~
50 or 60 Hz
