31.3.2 Power supply related error messages

User's manual
General error messages
ERROR EXPLANATION
CODE
E6.09 Emergency stop -safety circuit error.
WARNING
If a fuse has blown, contact your Planmeca dealer. Fuses must be changed
only by a qualified Planmeca service technician.
Power supply related error messages
ERROR EXPLANATION
CODE
E7 Power supply related error messages. IPS voltage failure on
MCB.
E9 Internal operating voltage too low. Unit functionality may be
limited.
E10 Internal operating voltage too high.
E11.1 OP-light fuse (F5) and/or Water heater fuse (F7) has blown on
the MCB.
E11.2 Separator fuse (F6) and/or Syringe heater fuse (F8) has blown
on the MCB.
E11.3 Either of the +24V electronics fuses (F9 or F10) has blown on
the MCB.
E11.4 Rectifier D5 or D1 short circuit or either of the 24V electronics
fuses (F3 or F4) has blown on the MCB. Chair, instrument and
headrest control not allowed.
E11.5 Separator fuse (F5) has blown on the MCB.
E11.6 Water heater fuse (F6) has blown on the MCB.
E11.7 Syringe heater fuse (F7) has blown on the MCB.
E11.8 Polymerisation light fuse (F8) has blown on the MCB.
E12.1 SELV voltage too low. Unit functionality may be limited.
E12.2 SELV voltage too high.
E13 Mains frequency outside acceptable range.
E14 IPS temperature measurement sensor error.
E15 IPS heatsink is running too hot on MCB.
E16 Attached scaler electronics is of new type.
E16.1 New type of scaler electronics is attached to MCB.
Update MCB software.
E16.2 New type of scaler electronics is attached to IMUX.
Update MCB software.
