23 Operating instruments
Turning off intraoral camera

23.11 Planmeca intraoral scanner

23.11.1 Operating intraoral scanner from foot control

168 Planmeca Compact i
Deactivate the intraoral camera from the dental unit when you have finished
working with it.
Deactivate the intraoral camera with the foot control by pushing the right-
side knob up (factory default setting).
The dental unit can also be configured so that the intraoral camera is
deactivated when you push the foot control's left-side knob up or when you
press the Flexy button. Contact your Planmeca dealer.
When the camera is deactivated, the indicator light on the handpiece goes
off. Return the intraoral camera to its holder.
The Planmeca intraoral scanner is used together with Planmeca Romexis
and Planmeca PlanCAD Easy software. The scanner is mainly operated with
the software, but to make the scanning procedure easier, some of the
operations can also be performed from the dental unit's foot control.
The intraoral scanner is placed in the Flexy-holder.
CAUTION
Make sure that you attach the intraoral scanner connector the right way into
the USB 3.0 port for the scanner on the cuspidor. If the connector is turned
the wrong way, it will not go into the port. Use of unnecessary force will
break the connector.
NOTE
There are three USB ports on the cuspidor. Make sure you attach the
connector to the right port, see section "Cuspidor" on page 30.
NOTE
To avoid splashes on the scanner, remove it from the dental unit after use
and place it on the table stand.
For more information, see
The control panel guides you how to operate the intraoral scanner from the
foot control.
Planmeca FIT user's manual .
