14 Foot control
Micromotor, turbine
Action
Pedal left / pedal right
Pedal down, short activation
Pedal down, long activation
Scaler
Action
Pedal left / pedal right
Pedal down, short activation
Unit controlled polymerisation light
Action
Pedal left / pedal right / pedal down
Intraoral camera
Action
Pedal left / pedal right
Pedal down
Intraoral scanner
Action
Pedal left
Pedal right
Pedal down, short activation
Pedal down, long activation

14.4 Wireless foot control

Power level
78 Planmeca Compact i
NOTE
The wireless foot control is an optional feature.
The standard foot control and the wireless foot control can not be used
simultaneously. Should such a situation occur, the standard foot control
overrides the wireless foot control.
When the wireless foot control has been idle for 2 hours, it goes into sleep
mode. You are notified about this with a message on the control panel. The
sleep mode is also indicated by a battery symbol on the control panel. Wake
up the foot control by pressing the foot control handle.
Before using the wireless foot control, check the power level of its battery.
The power level is indicated by a battery symbol on the control panel.
Sleep mode Full
Function
Drive instrument
Change spray water & air / air / off
Manual chip blow; activated for as long as the pedal is
pushed and held down
Function
Drive instrument
Change spray 1 / 2 / off
Function
Start / stop instrument
Function
Freeze / unfreeze picture
Save still picture
Function
Move upward in the list of scan type selection tools
Move downward in the list of scan type selection tools
Start scanning
Take image
< 40% full < 20% full
