Powering Up
To power on the unit, connect the provided IEC power cable between the rear panel power
connector and an AC power source. During power-up, the following occurs in the order
listed:
1.
2.
3.
4.
Status LED indicators
•
Input signal LEDs — These eight LEDs light green for their corresponding inputs
when active video content is detected on that input.
•
Output signal LEDs — Output LEDs 1, 2, and Loop light green when active video
is being output, and blink amber when output video and sync are disabled.
Input HDCP LEDs — These eight LEDs light green for each input signal that is
•
HDCP-encrypted.
•
Output HDCP LEDs — These three LEDs light green for an output when it is
currently HDCP-encrypted.
•
DTP2 and DTP Input LEDs — These two LEDs light green if DTP or DTP2 power
has been enabled on the corresponding input.
•
DTP2 and DTP Output LEDs — These Output LEDs light green if DTP or DTP2
power has been enabled on DTP output 2.
Menu and Enter buttons — (see
these buttons to access and navigate the on-screen display menu system (scaled DTP2
output only).
Navigation buttons — Press these buttons to navigate through the on-screen display
menu system or change settings (scaled DTP2 output only).
Mic and Volume knobs and LED indicators — Rotate the
microphone level. Rotate the
(configurable, see the DTP2 CrossPoint 82 PCS Help File for more information). The
eight LED indicators for each knob light according to the level being adjusted. The LEDs
light in order from bottom to top to indicate steps from 0% to 100% of the set limits.
The LEDs blink when levels are approaching the lower or upper limits.
IPCP Pro LED indicators (IPCP models only) — These LEDs light to indicate
status of the IPCP Pro module ports (see the IPCP Pro Series User Guide, available at
www.extron.com, for details).
All backlit buttons (the input buttons and the Logo button) blink amber, red, and green
for approximately 15 seconds.
The backlit buttons light steadily amber and remain lit for approximately 15 seconds.
On IPCP models, the RTS and I/O IPCP LEDs light and remain lit.
The backlit buttons blink in sequence once, then turn off.
When the unit is ready for operation:
•
If input or output signals are present, the appropriate input and output LEDs light.
•
If a logo has been selected, the Logo button lights amber.
The green Mic and Volume LEDs light to the level previously set.
•
