HDCP 2.2 compliant — Ensures display of content-protected 4K video media and
•
maintains interoperability with earlier versions of HDCP.
•
Integrated audio digital signal processor with ProDSP 64-bit processing — The DTP2
CrossPoint 82 features 64-bit floating-point audio DSP processing, which maintains
very wide dynamic range and audio signal transparency to simplify gain stage
management while reducing the possibility of DSP signal clipping.
•
Available with energy efficient Class D stereo or mono amplifier:
•
2 x 50 watts @ 4 ohms
2 x 25 watts @ 8 ohms
•
•
1 x 100 watts @ 70 volts
DTP2 CrossPoint 82 power amplifiers feature an advanced Class D amplifier design
with Class D Ripple Suppression (CDRS), an Extron-patented technology that provides
a smooth, clean audio waveform and an improvement in signal fidelity over conventional
Class D amplifier designs. CDRS eliminates the high frequency switching ripple
characteristic of Class D amplifiers, a source of RF emissions, which can interfere with
sensitive AV equipment such as wireless microphones.
Available with an integrated IPCP Pro 355M control processor — IPCP models
•
include a built-in IPCP Pro 355M control processor for complete AV system operation.
•
Supports TouchLink Pro touchpanels, eBUS button panels, and Network Button
Panels.
•
Integrated three-port AV LAN switch allows AV devices to be isolated from the
corporate network — Enables local control of AV devices connected to the AV
LAN switch while isolating the AV LAN network traffic from outside interference or
intrusion.
AV LAN permits only communications from the Ethernet port for remote
•
management and firmware updates to Extron devices — Allows Extron devices on
the AV LAN to receive firmware updates and be remotely monitored, managed, and
controlled through Extron GlobalViewer Enterprise.
•
Supports secure industry standard communications protocols — Uses industry
standard communication protocols, including HTTP that is unsecured, HTTPS,
SSH, SFTP, SMTP, NTP, Discovery Service, DHCP, DNS, ICMP, and IPv4.
•
Supports LinkLicense — Extron LinkLicense enhances the capabilities of Extron Pro
Series control systems.
•
Two bidirectional RS-232 ports with software handshaking — Captive screw serial
ports that can control two RS-232 devices.
•
One bidirectional RS-232/RS-422/RS-485 port with hardware and software
handshaking — Captive screw serial port that can communicate with one
RS-232/RS-422/RS-485 serially controlled device.
•
Two IR/Serial ports for one-way control of external devices
•
Four Digital I/O ports — Allows for interfacing with other systems in the room.
•
Four relays for controlling room functions — Enables control of lighting, screen
settings, and other device functions.
eBUS port for connecting eBUS button panels and accessories
•
•
Ethernet monitoring and control on each Ethernet port — Manage, monitor, and
control AV devices using a standard Ethernet network.
DHCP server for AV LAN — Automatically distributes IP addresses and network
•
configuration parameters for AV devices connected to the local AV LAN, which
streamlines system setup and management.
DTP2 CrossPoint 82 Scaling Presentation Matrix Switchers • Introduction
4
