Compatible with CATx shielded twisted pair cable — The DTP2 CrossPoint 82
•
supports a maximum transmission distance of 330 feet (100 meters) for all compatible
resolutions when used with CATx shielded twisted pair cable. Shielded twisted pair
cabling with solid center conductor sizes of 24 AWG or better is recommended for
optimal performance.
Remote powering of select DTP transmitters and receivers — The DTP2
•
CrossPoint 82 can provide power to select DTP or DTP2 transmitters and receivers over
the twisted pair connection, eliminating the need for a separate power supply at the
remote unit.
•
Accepts additional analog stereo audio — Supports stereo analog audio signals for
simultaneous transmission over the same shielded twisted pair cable.
Bidirectional RS-232 and IR pass-through for AV device control — Bidirectional
•
RS-232 control and IR signals can be transmitted alongside the video signal over the
DTP connection, allowing the remote device to be controlled without the need for
additional cabling. Bidirectional control extension eliminates the need for control system
wiring to remote devices.
Compatible with all DTP-enabled products, plus XTP CrossPoint matrix
•
switchers — Enables mixing and matching with desktop and wallplate endpoints, as
well as other DTP and DTP2-enabled products to meet application requirements. The
DTP2 CrossPoint 82 presentation matrix switcher can be integrated with XTP and XTP II
CrossPoint matrix switchers to provide connectivity between presentation spaces and a
larger, facility-wide system.
•
DTP2 output is compatible with HDBaseT-enabled devices — The
DTP2 CrossPoint 82 can be configured to send video and embedded audio, plus
bidirectional RS-232 and IR signals to an HDBaseT-enabled display.
•
User-selectable HDCP authorization for DTP2 and HDMI inputs — Allows
inputs 2 through 8 to appear HDCP compliant or non-HDCP compliant to the
connected source, which is beneficial if the source automatically encrypts all content
when connected to an HDCP-compliant device. Protected material is not passed in
non-HDCP mode.
•
Key Minder continuously verifies HDCP compliance for quick, reliable
switching — Key Minder authenticates and maintains continuous HDCP encryption
between input and output devices to ensure quick and reliable switching in professional
AV environments, while enabling simultaneous distribution of a single source signal to
one or more displays.
Comprehensive EDID management — Use Product Configuration Software (PCS)
•
to access EDID Minder for setting video input EDID, capturing EDID from connected
displays, or uploading custom EDID files. Proper EDID management ensures that
sources and displays are easily integrated into a system resulting in optimized system
operation. Freely downloadable EDID Manager 2.0 software is available for advanced
EDID editing and creating custom EDID files.
•
EDID Minder automatically manages EDID communication between connected
devices — EDID Minder ensures that the source powers up properly and reliably
outputs content for display.
•
SpeedSwitch technology provides exceptional switching speed for
HDCP-encrypted content.
•
Supports custom EDID and output resolutions — User-defined scaling output
resolutions can be supported by uploading custom EDID files or capturing EDID from a
display or other destination device.
DTP2 CrossPoint 82 Scaling Presentation Matrix Switchers • Introduction
7
