Operations

Powering on the Transmitter

To power on the DTP2 T 212 transmitter:
1.
2.
3.
4.
Signal status LEDs — (see
• Inputs — Each input has a corresponding Signal LED, which lights when a source
is connected to the input port and TMDS clock activity is detected on it.
NOTE: If the source device connected to the selected input is HDCP encrypted
(requires HDCP authentication), the corresponding signal LED may not light
unless HDCP has been authenticated.
• Outputs — The Outputs signal LED lights when an active sink (output) device is
connected to the HDMI output.
HDCP status LEDs —
• Inputs — Each input has a corresponding HDCP LED. If the connected source
requires HDCP, the corresponding LED lights when authentication is successful.
NOTE: HDCP is authenticated on each input regardless of the currently
selected source.
Outputs — The Outputs HDCP LED light if the currently selected input requires
•
HDCP and the connected output device has been successfully authenticated.
NOTE: HDCP is re-authenticated on the output whenever a new input is
selected.
NOTE: All front panel LEDs flash three times simultaneously when Executive Mode
(front panel lockout) is enabled or disabled via SIS Commands (see
Lockout (unsolicited)
Mode) on page 30).
Connect all input and output devices to the rear panel ports on the transmitter (see
Rear Panel Features on page 6 for the rear panel connections).
Power on the display.
Power on the DTP2 T 212 — Connect the power supply to the 2-pole captive screw
power inlet on the transmitter rear panel.
After approximately 4 seconds, the following happens:
• The unit performs a self-test, during which the front panel Auto Switch, Inputs,
Signal, and HDCP LEDs blink constantly. When the self-test completes, the LEDs
blink once to indicate the transmitter is fully functional.
• The transmitter reads the available EDID information from the connected output
device and writes it to memory on each input.
Power on the input devices.
figure 7 on page 14)
on page 42) or PCS (see Front Panel Lockout (Exec
Front Panel
DTP2 T 212 • Operation 15
