Device Info Panel

The Device Info panel (see figure 48,
and part number, with the option to edit the device name. The panel also contains an
Extron link which opens
Setting the device name
To edit the device name (TCP/IP hostname), click the Edit button in the lower-left corner of
the Device Info panel. The Device Info Settings dialog box opens.
Figure 49.
To change the name:
1. Click on the default name in the Device Name field (see figure 49,
appears. (The default name is the model name followed by -xx-xx-xx, where
xx-xx-xx are the last six characters of the unit MAC address.)
2. Enter a name for the DTP2 CrossPoint 82.
3. Click Save to apply the new name and close the dialog box, or click Cancel to close
the dialog box without renaming the device.

Inputs Panel

The Inputs panel (see figure 48,
signal as well as its HDCP status.
The following HDCP status indicators may be displayed for a connected input:
Symbol
No Signal
The names of inputs with video-only ties to an output are preceded by a green projector
icon. Those with audio-only ties are preceded by a red speaker icon. Those with audio and
video ties have no icons preceding them.
To view the status and type of all inputs, click the link (named 7 More) in the lower-left corner
of the Inputs panel to view the Inputs dialog box (see
example).
DTP2 CrossPoint 82 Scaling Presentation Matrix Switchers • Internal Web Pages
1
www.extron.com
Device Info Settings Dialog Box
) displays the name and signal type of the active input
2
Definition
The signal is HDCP encrypted.
The signal is not encrypted.
There is no signal detected.
) displays device name, brief product description,
in a new window.
1
figure 50 on page 107 for an
). A cursor
106
