Supports popular Building Management System (BMS) protocols, such as BACnet,
•
KNX, and DALI — These protocols allow for centralized monitoring and control
of mechanical and electrical systems that include HVAC, lighting, power, and
closed-circuit camera control.
•
Supports 10/100/1000Base-T Ethernet protocol
Supports Ethernet-controllable devices — Allows for control of multiple Ethernet
•
enabled AV devices such as displays, switchers, and sources.
•
Automatic clock synchronization allows a touchpanel to display the accurate time
and date.
•
Supports control system synchronization — Synchronization allows users to retain
and recover the state of their configured endpoints in case of network or power
failure.
•
Front panel port status indicators
Multi-level password protection — Allows security to be set based on user roles.
•
•
Fully customizable using Extron control system software — GUI Designer can be
combined with Global Configurator Plus or Global Configurator Professional.
•
Create controller groups — Allows multiple IP Link Pro control processors to be
grouped together to function as one when configured with Global Configurator
Professional.
•
Library of enhanced Extron Certified device drivers — Device drivers allow Extron
products to control various display and source devices, such as projectors, flat
panel displays, and Blu-ray Disc players. Extron has produced fully tested Ethernet,
serial, and IR device drivers.
Supports TouchLink Pro touchpanels, eBUS button panels, and Network Button
•
Panels
•
Integrated three-port AV LAN switch allows AV devices to be isolated from the
corporate network — Enables local control of AV devices connected to the AV LAN
switch while isolating the AV LAN network traffic from outside interference or intrusion.
•
AV LAN permits communications only from the Ethernet port for remote
management and firmware updates to Extron devices — Allows Extron devices
on the AV LAN to receive firmware updates and be remotely monitored, managed, and
controlled through Extron GlobalViewer Enterprise.
•
Supports secure industry standard communications protocols — Uses industry
standard communication protocols, including HTTP that is unsecured, HTTPS, SSH,
SFTP, SMTP, NTP, Discovery Service, DHCP, DNS, ICMP, and IPv4.
•
Supports LinkLicense
Series control systems.
Two bidirectional RS-232 ports with software handshaking — Captive screw
•
serial ports can control two RS-232 devices.
One bidirectional RS-232/RS-422/RS-485 port with hardware and software
•
handshaking — Captive screw serial port that can communicate with one
RS-232/RS-422/RS-485 serially controlled device.
Two IR/Serial ports for one-way control of external devices
•
•
Four Digital I/O ports — Allows for interfacing with other systems in the room.
•
Four relays for controlling room functions — Enables control of lighting, screen
settings, and other device functions.
•
eBUS port for connecting eBUS button panels and accessories
DTP2 CrossPoint 82 Scaling Presentation Matrix Switchers • Introduction
— Extron LinkLicense enhances the capabilities of Extron Pro
®
5
