Parameter Descriptions
13-10 Comparator Operand
Array [6]
Option: Function:
[112] Logic rule 2 The result of Logic rule 2.
[113] Logic rule 3 The result of Logic rule 3.
[114] Logic rule 4 The result of Logic rule 4.
[115] Logic rule 5 The result of Logic rule 5.
[120] SL Time-out 0 The result of SLC timer 0.
[121] SL Time-out 1 The result of SLC timer 1.
[122] SL Time-out 2 The result of SLC timer 2.
[123] SL Time-out 3 The result of SLC timer 3.
[124] SL Time-out 4 The result of SLC timer 4.
[125] SL Time-out 5 The result of SLC timer 5.
[126] SL Time-out 6 The result of SLC timer 6.
[127] SL Time-out 7 The result of SLC timer 7.
[130] Digital input DI18 Digital input 18. High = True.
[131] Digital input DI19 Digital input 19. High = True.
[132] Digital input DI27 Digital input 27. High = True.
[133] Digital input DI29 Digital input 29. High = True.
[134] Digital input DI32 Digital input 32. High = True.
[135] Digital input DI33 Digital input 33. High = True.
[150] SL digital output Use the result of the SLC output A.
A
[151] SL digital output B Use the result of the SLC output B.
[152] SL digital output Use the result of the SLC output C.
C
[153] SL digital output Use the result of the SLC output D.
D
[154] SL digital output E Use the result of the SLC output E.
[155] SL digital output F Use the result of the SLC output F.
[160] Relay 1 Relay 1 is active
[161] Relay 2 Relay 2 is active
[180] Local referecnce High when 3-13 Reference Site = [2]
active Local or when 3-13 Reference Site is [0]
Linked to hand Auto, at the same time
as the LCP is in Hand On mode.
[181] Remote reference High when 3-13 Reference Site= [1]
active Remote or [0] Linked to hand/auto,
while the LCP is in Auto On mode.
[182] Start command High when there is an active start
command, and no stop command.
[183] Drive stopped A stop command (Jog, Stop, Qstop,
Coast) is issued – and not from the
SLC itself.
[185] Drive in hand High when the frequency converter is
mode in hand mode.
®
VLT AutomationDrive Programming Guide
13-10 Comparator Operand
Array [6]
Option:
[186] Drive in auto
[187] Start command
[190] Digital input x30 2
[191] Digital input x30 3
[192] Digital input x30 4
[193] Digital input x46 1
[194] Digital input x46 2
[195] Digital input x46 3
[196] Digital input x46 4
[197] Digital input x46 5
[198] Digital input x46 6
[199] Digital input x46 7
13-11 Comparator Operator
Array [6]
Option:
[0] <
[1] ≈ (equal)
[2] >
[5] TRUE longer
[6] FALSE longer
[7] TRUE shorter
[8] FALSE
13-12 Comparator Value
Array [6]
Range:
Size related
®
MG33MG02 - VLT is a registered Danfoss trademark
Function:
High when the frequency converter is
mode in auto mode.
given
Function:
Select the operator to be used in the
comparison. This is an array parameter
containing comparator operators 0 to 5.
The result of the evaluation is TRUE, when the
variable selected in 13-10 Comparator Operand
is smaller than the fixed value in
13-12 Comparator Value. The result is FALSE, if
the variable selected in 13-10 Comparator
Operand is greater than the fixed value in
13-12 Comparator Value.
The result of the evaluation is TRUE, when the
variable selected in 13-10 Comparator Operand
is approximately equal to the fixed value in
13-12 Comparator Value.
Inverse logic of option < [0].
than..
than..
than..
shorter
than..
Function:
[-100000 - Enter the 'trigger level' for the
*
100000 ] variable that is monitored by this
comtor. This is an array parameter
containing comtor values 0 to 5.
