Parameter Lists
Par. No. # Parameter description
12-67 Threshold Counters
12-68 Cumulative Counters
12-69 Ethernet PowerLink Status
12-8* Other Ethernet Services
12-80 FTP Server
12-81 HTTP Server
12-82 SMTP Service
Transparent Socket Channel
12-89 Port
12-9* Advanced Ethernet Services
12-90 Cable Diagnostic
12-91 Auto Cross Over
12-92 IGMP Snooping
12-93 Cable Error Length
12-94 Broadcast Storm Protection
12-95 Broadcast Storm Filter
12-96 Port Config
12-98 Interface Counters
12-99 Media Counters
4.1.15 13-** Smart Logic
Par. No. # Parameter description
13-0* SLC Settings
13-00 SL Controller Mode
13-01 Start Event
13-02 Stop Event
13-03 Reset SLC
13-1* Comparators
13-10 Comparator Operand
13-11 Comparator Operator
13-12 Comparator Value
13-1* RS Flip Flops
13-15 RS-FF Operand S
13-16 RS-FF Operand R
13-2* Timers
13-20 SL Controller Timer
13-4* Logic Rules
13-40 Logic Rule Boolean 1
13-41 Logic Rule Operator 1
13-42 Logic Rule Boolean 2
13-43 Logic Rule Operator 2
13-44 Logic Rule Boolean 3
13-5* States
13-51 SL Controller Event
13-52 SL Controller Action
®
VLT AutomationDrive Programming Guide
Default value 4-set-up
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
[0] Disabled 2 set-ups
[0] Disabled 2 set-ups
[0] Disabled 2 set-ups
ExpressionLimit 2 set-ups
[0] Disabled 2 set-ups
[1] Enabled 2 set-ups
[1] Enabled 2 set-ups
0 N/A 1 set-up
-1 % 2 set-ups
[0] Broadcast only 2 set-ups
ExpressionLimit 2 set-ups
4000 N/A All set-ups
0 N/A All set-ups
Default value 4-set-up
ExpressionLimit 2 set-ups
ExpressionLimit 2 set-ups
ExpressionLimit 2 set-ups
[0] Do not reset SLC All set-ups
ExpressionLimit 2 set-ups
ExpressionLimit 2 set-ups
ExpressionLimit 2 set-ups
ExpressionLimit 2 set-ups
ExpressionLimit 2 set-ups
ExpressionLimit 1 set-up
ExpressionLimit 2 set-ups
ExpressionLimit 2 set-ups
ExpressionLimit 2 set-ups
ExpressionLimit 2 set-ups
ExpressionLimit 2 set-ups
ExpressionLimit 2 set-ups
ExpressionLimit 2 set-ups
®
