Danfoss VLT AutomationDrive FC 300 Programming Manual page 100

Parameter Descriptions
6-13 Terminal 53 High Current
Range:
20 mA [ par. 6-12 - 20
*
mA]
3 3
6-14 Terminal 53 Low Ref./Feedb. Value
Range:
0 [-999999.999 -
*
999999.999 ]
6-15 Terminal 53 High Ref./Feedb. Value
Range:
Size
related 999999.999
*
ReferenceFeed-
backUnit]
6-16 Terminal 53 Filter Time Constant
Range:
0.001 s [0.001 - 10
*
s]
3.8.3 6-2* Analog Input 2
Parameters for configuring the scaling and limits for
analog input 2 (terminal 54).
6-20 Terminal 54 Low Voltage
Range:
0.07 V [ -10.00 - par.
*
6-21 V]
98
Function:
Enter the high current value
corresponding to the high reference/
feedback set in 6-15 Terminal 53 High
Ref./Feedb. Value.
Function:
Enter the analog input scaling value
that corresponds to the low
voltage/low current set in
6-10 Terminal 53 Low Voltage and
6-12 Terminal 53 Low Current.
Function:
[-999999.999 - Enter the analog input
scaling value that
corresponds to the
maximum reference
feedback value set in
6-11 Terminal 53 High
Voltage and 6-13 Terminal
53 High Current.
Function:
NOTE
This parameter cannot be adjusted
while the motor is running.
Enter the time constant. This is a first-
order digital low pass filter time constant
for suppressing electrical noise in terminal
53. A high time constant value improves
dampening but also increases the time
delay through the filter.
Function:
Enter the low voltage value. This analog
input scaling value should correspond
to the minimum reference value, set in
3-02 Minimum Reference. See also
3.5 Parameters: 3-** Reference/Ramps.
MG33MG02 - VLT
®
VLT AutomationDrive Programming Guide
6-21 Terminal 54 High Voltage
Range:
10 V
*
10 V]
6-22 Terminal 54 Low Current
Range:
0.14
mA
*
6-23 Terminal 54 High Current
Range:
20 mA
*
6-24 Terminal 54 Low Ref./Feedb. Value
Range:
0 ReferenceFeed-
backUnit
6-25 Terminal 54 High Ref./Feedb. Value
Range:
Size related
®
is a registered Danfoss trademark
Function:
[ par. 6-20 - Enter the high voltage value. This analog
input scaling value should correspond to
the high reference/feedback value set in
6-25 Terminal 54 High Ref./Feedb. Value.
Function:
[ 0 - par. Enter the low current value. This reference
6-23 mA] signal should correspond to the minimum
reference value, set in 3-02 Minimum
Reference. The value must be set at >2 mA
in order to activate the Live Zero Time-out
Function in 6-01 Live Zero Timeout
Function.
Function:
[ par. 6-22 - Enter the high current value
20 mA] corresponding to the high reference/
feedback value set in 6-25 Terminal 54
High Ref./Feedb. Value.
[-999999.999 -
999999.999
*
ReferenceFeed-
backUnit]
Function:
[-999999.999 - Enter the analog input
*
999999.999 scaling value that
ReferenceFeed- corresponds to the
backUnit] maximum reference
feedback value set in
3-03 Maximum Reference.
Function:
Enter the analog
input scaling value
that corresponds to
the minimum
reference feedback
value set in
3-02 Minimum
Reference.
