Parameter Descriptions
0-20 Display Line 1.1 Small
Option:
[1616] Torque [Nm]
[1617] Speed [RPM]
3 3
[1618] Motor Thermal
[1619] KTY sensor temperature
[1620] Motor Angle
[1621] Torque [%] High Res.
[1622] Torque [%]
[1625] Torque [Nm] High
[1630] DC Link Voltage
[1632] Brake Energy /s
[1633] Brake Energy /2 min
[1634] Heatsink Temp.
[1635] Inverter Thermal
[1636] Inv. Nom. Current
[1637] Inv. Max. Current
[1638] SL Controller State
[1639] Control Card Temp.
[1648] Speed Ref. After Ramp
[RPM]
[1650] External Reference
[1651] Pulse Reference
[1652] Feedback[Unit]
[1653] Digi Pot Reference
[1657] Feedback [RPM]
28
®
VLT AutomationDrive Programming Guide
Function:
Actual motor torque in Nm
Speed in RPM (revolutions per
minute) i.e. the motor shaft
speed in closed loop.
Thermal load on the motor,
calculated by the ETR function.
Present motor load as a
percentage of the rated motor
torque.
Intermediate circuit voltage in
the frequency converter.
Present brake power transferred
to an external brake resistor.
Stated as an instantaneous
value.
Brake power transferred to an
external brake resistor. The
mean power is calculated
continuously for the most
recent 120 s.
Present heat sink temperature
of the frequency converter. The
cut-out limit is 95 ±5 °C; cutting
back in occurs at 70 ±5 °C.
Percentage load of the inverters.
Nominal current of the
frequency converter.
Maximum current of the
frequency converter.
State of the event executed by
the control.
Temperature of the control card.
Sum of the external reference as
a percentage, i.e. the sum of
analog/pulse/bus.
Frequency in Hz connected to
the digital inputs (18, 19 or 32,
33).
Reference value from
programmed digital input(s).
®
MG33MG02 - VLT is a registered Danfoss trademark
0-20 Display Line 1.1 Small
Option:
[1660] Digital Input
[1661] Terminal 53 Switch
Setting
[1662] Analog Input 53
[1663] Terminal 54 Switch
Setting
[1664] Analog Input 54
[1665] Analog Output 42 [mA] Actual value at output 42 in
[1666] Digital Output [bin]
[1667] Freq. Input #29 [Hz]
[1668] Freq. Input #33 [Hz]
[1669] Pulse Output #27 [Hz]
[1670] Pulse Output #29 [Hz]
[1671] Relay Output [bin]
[1672] Counter A
[1673] Counter B
[1674] Prec. Stop Counter
[1675] Analog In X30/11
[1676] Analog In X30/12
[1677] Analog Out X30/8 [mA]
Function:
Signal states form the 6 digital
terminals (18, 19, 27, 29, 32 and
33). There are 16 bits in total,
but only six of them are used.
Input 18 corresponds to the
leftmost of the used bits. Signal
low = 0; Signal high = 1.
Setting of input terminal 54.
Current = 0; Voltage = 1.
Actual value at input 53 either
as a reference or protection
value.
Setting of input terminal 54.
Current = 0; Voltage = 1.
Actual value at input 54 either
as reference or protection value.
mA. Use 6-50 Terminal 42 Output
to select the value to be shown.
Binary value of all digital
outputs.
Actual value of the frequency
applied at terminal 29 as an
impulse input.
Actual value of the frequency
applied at terminal 33 as an
impulse input.
Actual value of impulses applied
to terminal 27 in digital output
mode.
Actual value of impulses applied
to terminal 29 in digital output
mode.
Application dependent (e.g. SLC
Control)
Application dependent (e.g. SLC
Control)
Display the actual counter value.
Actual value at input X30/11
either as reference or protection
value.
Actual value at input X30/12
either as reference or protection
value.
Actual value at output X30/8 in
mA. Use 6-60 Terminal X30/8
