Danfoss VLT AutomationDrive FC 300 Programming Manual page 156

Parameter Descriptions
16-72 Counter A
Range:
0 [-2147483648 -
*
2147483647 ]
3 3
16-73 Counter B
Range:
0 [-2147483648 -
*
2147483647 ]
16-74 Prec. Stop Counter
Range:
0 [0 - 2147483647 ] Returns the actual counter value of
*
16-75 Analog In X30/11
Range:
0 [-20 - 20 ] View the actual value at input X30/11 of MCB
*
16-76 Analog In X30/12
Range:
0 [-20 - 20 ] View the actual value at input X30/12 of MCB
*
16-77 Analog Out X30/8 [mA]
Range:
0 [0 - 30 ]
*
16-78 Analog Out X45/1 [mA]
Range:
0 [0 - 30 ] View the actual value at output X45/1. The value
*
16-79 Analog Out X45/3 [mA]
Range:
0 [0 - 30 ] View the actual value at output X45/3. The value
*
154
VLT
Function:
View the present value of Counter A.
Counters are useful as comparator
operands, see 13-10 Comparator Operand.
The value can be reset or changed either
via digital inputs (parameter group 5-1*
Digital Inputs) or by using an SLC action
(13-52 SL Controller Action).
Function:
View the present value of Counter B.
Counters are useful as comparator
operands (13-10 Comparator Operand).
The value can be reset or changed either
via digital inputs (parameter group 5-1*
Digital Inputs) or by using an SLC action
(13-52 SL Controller Action).
Function:
precise counter (1-84 Precise Stop
Counter Value).
Function:
101.
Function:
101.
Function:
View the actual value at input X30/8 in mA.
Function:
shown reflects the selection in 6-70 Terminal X45/1
Output.
Function:
shown reflects the selection in 6-80 Terminal X45/3
Output.
MG33MG02 - VLT
®
AutomationDrive Programming Guide
3.17.5 16-8* Fieldbus & FC Port
Parameters for reporting the BUS references and control
words.
16-80 Fieldbus CTW 1
Range:
0 [0 - 65535 ] View the two-byte Control word (CTW)
*
16-82 Fieldbus REF 1
Range:
0 [-200 -
*
200 ]
16-84 Comm. Option STW
Range:
0 [0 - 65535 ] View the extended Fieldbus comm. option
*
16-85 FC Port CTW 1
Range:
0 [0 - 65535 ] View the two-byte Control word (CTW)
*
16-86 FC Port REF 1
Range:
0 [-200 -
*
200 ]
16-87 Bus Readout Alarm/Warning
Range:
0 [0 - 65535 ] Alarm and Warning numbers in hex as
*
®
is a registered Danfoss trademark
Function:
received from the Bus-Master. Interpretation of
the Control word depends on the Fieldbus
option installed and the Control word profile
selected in 8-10 Control Profile.
For more information, refer to the relevant
Fieldbus manual.
Function:
View the two-byte word sent with the control
word form the Bus-Master to set the
reference value.
For more information, refer to the relevant
fieldbus manual.
Function:
status word.
For more information, refer to the relevant
Fieldbus manual.
Function:
received from the Bus-Master. Interpretation of
the control word depends on the Fieldbus
option installed and the Control word profile
selected in 8-10 Control Profile.
Function:
View the two-byte Status word (STW) sent to
the Bus-Master. Interpretation of the Status
word depends on the fieldbus option installed
and the Control word profile selected in
8-10 Control Profile.
Function:
displayed in the Alarm log. The High byte
contains the Alarm, the Low byte the Warning.
The Alarm number is the first one that
occurred after the last reset.
