Parameter Descriptions
0-04 Operating State at Power-up (Hand)
Option: Function:
(applied by [Hand On/Off]) as before the
frequency converter was powered down.
[1] Forced stop, Restarts the frequency converter with a saved
ref=old local reference, after mains voltage reappears
and after pressing [Hand On].
[2] Forced stop, Resets the local reference to 0 upon restarting
ref=0 the frequency converter.
0-09 Performance Monitor
Range:
0 % [0 - 100 %]
*
3.2.2 0-1* Set-up Operations
Define and control the individual parameter set-ups.
The frequency converter has four parameter set-ups that
can be programmed independently of each other. This
makes the frequency converter very flexible and able to
solve advanced control functionality problems, often
saving the cost of external control equipment. For example
these can be used to program the frequency converter to
operate according to one control scheme in one set-up
(e.g. motor 1 for horizontal movement) and another
control scheme in another set-up (e.g. motor 2 for vertical
movement). Alternatively they can be used by an OEM
machine builder to identically program all their factory
fitted frequency converters for different machine types
within a range to have the same parameters and then
during production/commissioning simply select a specific
set-up depending on which machine the frequency
converter is installed on.
The active set-up (i.e. the set-up in which the frequency
converter is currently operating) can be selected in
0-10 Active Set-up and is displayed in the LCP. Using Multi
set-up it is possible to switch between set-ups with the
frequency converter running or stopped, via digital input
or serial communication commands. If it is necessary to
change set-ups whilst running, ensure 0-12 This Set-up
Linked to is programmed as required. Using 0-11 Edit Set-up
it is possible to edit parameters within any of the set-ups
whilst continuing the frequency converter operation in its
active set-up which can be a different set-up to that being
edited. Using 0-51 Set-up Copy it is possible to copy
parameter settings between the set-ups to enable quicker
commissioning if similar parameter settings are required in
different set-ups.
®
VLT AutomationDrive Programming Guide
0-10 Active Set-up
Option:
[0] Factory setup Cannot be changed. It contains the Danfoss
[1] Set-up 1
Function:
[2] Set-up 2
[3] Set-up 3
[4] Set-up 4
[9] Multi Set-up
Use 0-51 Set-up Copy to copy a set-up to one or all other
set-ups. Stop the frequency converter before switching
between set-ups where parameters marked 'not
changeable during operation' have different values. To
avoid conflicting settings of the same parameter within
two different set-ups, link the set-ups together using
0-12 This Set-up Linked to. Parameters which are 'not
changeable during operation' are marked FALSE in the
parameter lists in 4 Parameter Lists.
0-11 Edit Set-up
Option:
[0] Factory setup Cannot be edited but it is useful as a data
[1] Set-up 1
[2] Set-up 2
[3] Set-up 3
[4] Set-up 4
[9] Active Set-up Can also be edited during operation. Edit the
®
MG33MG02 - VLT is a registered Danfoss trademark
Function:
Select the set-up to control the frequency
converter functions.
data set, and can be used as a data source
when returning the other set-ups to a known
state.
[1] Set-up 1 to [4] Set-up 4 are the four
separate parameter set-ups within which all
parameters can be programmed.
Remote selection of set-ups using digital
inputs and the serial communication port. This
set-up uses the settings from 0-12 This Set-up
Linked to. Stop the frequency converter before
making changes to open- and closed loop
functions
Function:
Select the set-up to be edited (i.e.
programmed) during operation; either the
active set-up or one of the inactive set-ups.
source to return the other set-ups to a known
state.
[1] Set-up 1 to [4] Set-up 4 can be edited freely
during operation, independently of the active
set-up.
chosen set-up from a range of sources: LCP,
FC RS-485, FC USB or up to five fieldbus sites.
