5-40 Function Relay
Array [9]
(Relay 1 [0], Relay 2 [1], Relay 3 [2] (MCB 113), Relay 4 [3] (MCB
113), Relay 5 [4] (MCB 113), Relay 6 [5] (MCB 113), Relay 7 [6]
(MCB 105), Relay 8 [7] (MCB 105), Relay 9 [8] (MCB 105))
3 3
Option:
[16] Below speed, low
[17] Above speed, high
[18] Out of feedb. range Feedback is outside the range set in
[19] Below feedback,
low
[20] Above feedback,
high
[21] Thermal warning
[22] Ready,no thermal W Frequency converter is ready for
[23] Remote,ready,no
TW
[24] Ready, Voltage OK
[25] Reverse
[26] Bus OK
[27] Torque limit & stop
[28] Brake, no brake war Brake is active and there are no
[29] Brake ready, no
fault
88
®
VLT AutomationDrive Programming Guide
Function:
Output speed is lower than the
setting in 4-52 Warning Speed Low
Output speed is higher than the
setting in 4-53 Warning Speed High.
4-56 Warning Feedback Low and
4-57 Warning Feedback High.
Feedback is below the limit set in
4-56 Warning Feedback Low.
Feedback is above the limit set in
4-57 Warning Feedback High.
Thermal warning turns on when the
temperature exceeds the limit either
in motor, frequency converter, brake
resistor, or connected thermistor.
operation and there is no over-
temperature warning.
Frequency converter is ready for
operation and is in Auto On mode.
There is no over-temperature
warning.
Frequency converter is ready for
operation and the mains voltage is
within the specified voltage range
(see General Specifications section in
Design Guide).
The motor runs (or is ready to run)
clockwise when logic=0 and counter
clockwise when logic=1. The output
changes as soon as the reversing
signal is applied.
Active communication (no time-out)
via the serial communication port.
Use in performing a coasted stop
and frequency converter in torque
limit condition. If the frequency
converter has received a stop signal
and is in torque limit, the signal is
Logic '0'.
warnings.
Brake is ready for operation and
there are no faults.
MG33MG02 - VLT
5-40 Function Relay
Array [9]
(Relay 1 [0], Relay 2 [1], Relay 3 [2] (MCB 113), Relay 4 [3] (MCB
113), Relay 5 [4] (MCB 113), Relay 6 [5] (MCB 113), Relay 7 [6]
(MCB 105), Relay 8 [7] (MCB 105), Relay 9 [8] (MCB 105))
Option:
[30] Brake fault (IGBT)
[31] Relay 123
[32] Mech brake ctrl
[33] Safe stop active
[36] Control word bit 11 Activate relay 1 by control word from
[37] Control word bit 12 Activate relay 2 FC 302 only) by
[38] Motor feedback
error
[39] Tracking error
®
is a registered Danfoss trademark
Function:
Output is Logic '1' when the brake
IGBT is short-circuited. Use this
function to protect the frequency
converter if there is a fault on the
brake module. Use the digital
output/relay to cut out the main
voltage from the frequency
converter.
Digital output/relay is activated when
[0] Control Word is selected in
parameter group 8-** Comm. and
Options.
Selection of mechanical brake
control. When selected parameters in
parameter group 2-2* are active. The
output must be reinforced to carry
the current for the coil in the brake.
Usually solved by connecting an
external relay to the selected digital
output.
(FC 302 only) Indicates that the safe
stop on terminal 37 has been
activated.
fieldbus. No other functional impact
in the frequency converter. Typical
application: controlling auxiliary
device from fieldbus. The function is
valid when [0] FC profile in
8-10 Control Word Profile is selected.
control word from fieldbus. No other
functional impact in the frequency
converter. Typical application:
controlling auxiliary device from
fieldbus. The function is valid when
[0] FC profile in 8-10 Control Word
Profile is selected.
Failure in the speed feedback loop
from motor running in closed loop.
The output can eventually be used
to prepare switching the drive in
open loop in emergency case.
When the difference between
calculated speed and actual speed in
4-35 Tracking Error is larger than
selected the digital output/relay is
active.
