Parameter Descriptions
5-40 Function Relay
Array [9]
(Relay 1 [0], Relay 2 [1], Relay 3 [2] (MCB 113), Relay 4 [3] (MCB
113), Relay 5 [4] (MCB 113), Relay 6 [5] (MCB 113), Relay 7 [6]
(MCB 105), Relay 8 [7] (MCB 105), Relay 9 [8] (MCB 105))
Option: Function:
[40] Out of ref range Active when the actual speed is
outside settings in 4-52 Warning
Speed Low to 4-55 Warning Reference
High.
[41] Below reference, Active when actual speed is below
low speed reference setting.
[42] Above ref, high Active when actual speed is above
speed reference setting.
[43] Extended PID Limit
[45] Bus ctrl. Controls digital output/relay via bus.
The state of the output is set in
5-90 Digital & Relay Bus Control. The
output state is retained in the event
of bus time-out.
[46] Bus ctrl, 1 if Controls output via bus. The state of
timeout the output is set in 5-90 Digital &
Relay Bus Control. In the event of bus
time-out the output state is set high
(On).
[47] Bus ctrl, 0 if Controls output via bus. The state of
timeout the output is set in 5-90 Digital &
Relay Bus Control. In the event of bus
time-out the output state is set low
(Off).
[51] MCO controlled Active when an MCO 302 or MCO
305 is connected. The output is
controlled from option.
[60] Comparator 0 See parameter group 13-1*
Comparators. If Comparator 0 in SLC
is TRUE, the output will go high.
Otherwise, it will be low.
[61] Comparator 1 See parameter group 13-1*
Comparators. If Comparator 1 in SLC
is TRUE, the output will go high.
Otherwise, it will be low.
[62] Comparator 2 See parameter group 13-1*
Comparators. If Comparator 2 in SLC
is TRUE, the output will go high.
Otherwise, it will be low.
[63] Comparator 3 See parameter group 13-1*
Comparators. If Comparator 3 in SLC
is TRUE, the output will go high.
Otherwise, it will be low.
[64] Comparator 4 See parameter group 13-1*
Comparators. If Comparator 4 in SLC
®
VLT AutomationDrive Programming Guide
5-40 Function Relay
Array [9]
(Relay 1 [0], Relay 2 [1], Relay 3 [2] (MCB 113), Relay 4 [3] (MCB
113), Relay 5 [4] (MCB 113), Relay 6 [5] (MCB 113), Relay 7 [6]
(MCB 105), Relay 8 [7] (MCB 105), Relay 9 [8] (MCB 105))
Option:
[65]
[70]
[71]
[72]
[73]
[74]
[75]
[80]
[81]
[82]
[83]
®
MG33MG02 - VLT is a registered Danfoss trademark
Function:
is TRUE, the output will go high.
Otherwise, it will be low.
Comparator 5 See parameter group 13-1* Smart
Logic Control. If Comparator 5 in SLC
is TRUE, the output will go high.
Otherwise, it will be low.
Logic rule 0 See parameter group 13-4* Smart
Logic Control. If Logic Rule 0 in SLC is
TRUE, the output will go high.
Otherwise, it will be low.
Logic rule 1 See parameter group 13-4* Smart
Logic Control. If Logic Rule 1 in SLC is
TRUE, the output will go high.
Otherwise, it will be low.
Logic rule 2 See parameter group 13-4* Smart
Logic Control. If Logic Rule 2 in SLC is
TRUE, the output will go high.
Otherwise, it will be low.
Logic rule 3 See parameter group 13-4* Smart
Logic Control. If Logic Rule 3 in SLC is
TRUE, the output will go high.
Otherwise, it will be low.
Logic rule 4 See parameter group 13-4* Smart
Logic Control. If Logic Rule 4 in SLC is
TRUE, the output will go high.
Otherwise, it will be low.
Logic rule 5 See parameter group 13-4* Smart
Logic Control. If Logic Rule 5 in SLC is
TRUE, the output will go high.
Otherwise, it will be low.
SL digital output A See 13-52 SL Controller Action. Output
A is low on Smart Logic Action [32].
Output A is high on Smart Logic
Action [38].
SL digital output B See 13-52 SL Controller Action. Output
B is low on Smart Logic Action [33].
Output B is high on Smart Logic
Action [39].
SL digital output C See 13-52 SL Controller Action. Output
C is low on Smart Logic Action [34].
Output C is high on Smart Logic
Action [40].
SL digital output D See 13-52 SL Controller Action. Output
D is low on Smart Logic Action [35].
Output D is high on Smart Logic
Action [41].
