Parameter Descriptions
0-13 Readout: Linked Set-ups
Array [5]
Range: Function:
0 [0 - 255 ] View a list of all the set-ups linked by means of
*
0-12 This Set-up Linked to. The parameter has one
index for each parameter set-up. The parameter
value displayed for each index represents which
set-ups are linked to that parameter set-up.
Index
0
1
2
3
4
Table 3.2 Example: Set-up 1 and Set-up 2 are
linked
0-14 Readout: Edit Set-ups / Channel
Range: Function:
0 [-2147483648 - View the setting of 0-11 Edit Set-up for
*
2147483647 ] each of the four different communication
channels. When the number is displayed in
hex, as it is in the LCP, each number
represents one channel.
Numbers 1-4 represent a set-up number;
'F' means factory setting; and 'A' means
active set-up. The channels are, from right
to left: LCP, FC-bus, USB, HPFB1-5.
Example: The number AAAAAA21h means
that the FC bus selected Set-up 2 in
0-11 Edit Set-up, the LCP selected Set-up 1
and all others used the active set-up.
0-15 Readout: actual setup
Range: Function:
0 [0 - 255 ] Makes it possible to read out the active set-up,
*
also when multi set-up is selected in 0-10 Active
Set-up.
3.2.3 0-2* LCP Display
Define the variables displayed in the Graphical Local
Control Panel.
NOTE
Refer to 0-37 Display Text 1, 0-38 Display Text 2 and
0-39 Display Text 3 for information on how to write display
texts.
®
VLT AutomationDrive Programming Guide
LCP value
{0}
{1,2}
{1,2}
{3}
{4}
®
MG33MG02 - VLT is a registered Danfoss trademark
0-20 Display Line 1.1 Small
Option:
[0] None
[9] Performance Monitor
[15] Readout: actual setup
[37] Display Text 1
[38] Display Text 2
[39] Display Text 3
[748] PCD Feed Forward
[953] Profibus Warning Word
[1005] Readout Transmit Error
Counter
[1006] Readout Receive Error
Counter
[1007] Readout Bus Off
Counter
[1013] Warning Parameter
[1230] Warning Parameter
[1472] Legacy Alarm Word
[1473] Legacy Warning Word
[1474] Leg. Ext. Status Word
[1501] Running Hours
[1502] kWh Counter
[1580] Fan Running Hours
[1600] Control Word
[1601] Reference [Unit]
[1602] Reference %
[1603] Status Word
[1605] Main Actual Value [%]
[1609] Custom Readout
[1610] Power [kW]
[1611] Power [hp]
[1612] Motor Voltage
[1613] Frequency
[1614] Motor current
[1615] Frequency [%]
Function:
Select a variable for display in
line 1, left position.
No display value selected.
Present control word
Total reference (sum of digital/
analog/preset/bus/freeze ref./
catch up and slow-down) in
selected unit.
Total reference (sum of digital/
analog/preset/bus/freeze ref./
catch up and slow-down) in
percent.
Present status word.
Actual value as a percentage.
Actual power consumed by the
motor in kW.
Actual power consumed by the
motor in HP.
Voltage supplied to the motor.
Motor frequency, i.e. the output
frequency from the frequency
converter in Hz
Phase current of the motor
measured as effective value.
Motor frequency, i.e. the output
frequency from the frequency
converter in percent.
