Parameter Descriptions
3.19 Parameters: 18-** Data Readouts 2
18-36 Analog Input X48/2 [mA]
Range:
3 3
0 [-20 - 20 ] View the actual current measured at input
*
18-37 Temp. Input X48/4
Range:
0 [-500 - 500 ] View the actual temperature measured at
*
18-38 Temp. Input X48/7
Range:
0 [-500 - 500 ] View the actual temperature measured at
*
18-39 Temp. Input X48/10
Range:
0 [-500 - 500 ] View the actual temperature measured at
*
18-60 Digital Input 2
Range:
0 [0 - 65535 ] View the signal states from the active digital
*
18-90 Process PID Error
Range:
0 % [-200 - 200 %]
*
18-91 Process PID Output
Range:
0 % [-200 - 200 %]
*
18-92 Process PID Clamped Output
Range:
0 %
*
18-93 Process PID Gain Scaled Output
Range:
0 %
*
158
Function:
X48/2.
Function:
input X48/4. The temperature unit is based
on the selection in 35-00 Term. X48/4
Temperature Unit.
Function:
input X48/7. The temperature unit is based
on the selection in 35-02 Term. X48/7
Temperature Unit.
Function:
input X48/10. The temperature unit is based
on the selection in 35-04 Term. X48/10
Temperature Unit.
Function:
inputs. '0' = no signal, '1' = connected signal.
Function:
Function:
Function:
[-200 - 200 %]
Function:
[-200 - 200 %]
