Danfoss VLT AutomationDrive FC 300 Programming Manual page 195

Parameter Lists
Par. No. # Parameter description
18-92 Process PID Clamped Output
Process PID Gain Scaled
18-93 Output
4.1.21 30-** Special Features
Par. No. # Parameter description
30-0* Wobbler
30-00 Wobble Mode
30-01 Wobble Delta Frequency [Hz]
30-02 Wobble Delta Frequency [%]
Wobble Delta Freq. Scaling
30-03 Resource
30-04 Wobble Jump Frequency [Hz]
30-05 Wobble Jump Frequency [%]
30-06 Wobble Jump Time
30-07 Wobble Sequence Time
30-08 Wobble Up/ Down Time
30-09 Wobble Random Function
30-10 Wobble Ratio
30-11 Wobble Random Ratio Max.
30-12 Wobble Random Ratio Min.
30-19 Wobble Delta Freq. Scaled
30-2* Adv. Start Adjust
30-20 High Starting Torque Time [s]
High Starting Torque Current
30-21 [%]
30-22 Locked Rotor Protection
Locked Rotor Detection Time
30-23 [s]
30-8* Compatibility (I)
30-80 d-axis Inductance (Ld)
30-81 Brake Resistor (ohm)
30-83 Speed PID Proportional Gain
Process PID Proportional
30-84 Gain
4.1.22 32-** MCO Basic Settings
Par. No. # Parameter description
32-0* Encoder 2
32-00 Incremental Signal Type
32-01 Incremental Resolution
32-02 Absolute Protocol
32-03 Absolute Resolution
®
VLT AutomationDrive Programming Guide
Default value 4-set-up
0 % All set-ups
0 % All set-ups
Default value 4-set-up
[0] Abs. Freq., Abs.
Time All set-ups
5 Hz All set-ups
25 % All set-ups
[0] No function All set-ups
0 Hz All set-ups
0 % All set-ups
ExpressionLimit All set-ups
10 s All set-ups
5 s All set-ups
[0] Off All set-ups
1 N/A All set-ups
10 N/A All set-ups
0.1 N/A All set-ups
0 Hz All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit 1 set-up
ExpressionLimit All set-ups
0.100 N/A All set-ups
Default value 4-set-up
[1] RS422 (5V TTL) 2 set-ups
1024 N/A 2 set-ups
[0] None 2 set-ups
8192 N/A 2 set-ups
®
MG33MG02 - VLT is a registered Danfoss trademark
FC 302 Change Conver-
only during sion index
operation
FALSE -1
FALSE -1
FC 302 Change Conver-
only during sion index
operation
FALSE -
TRUE -1
TRUE 0
TRUE -
TRUE -1
TRUE 0
TRUE -3
TRUE -1
TRUE -1
TRUE -
TRUE -1
TRUE -1
TRUE -1
FALSE -1
x TRUE -2
x TRUE -1
x TRUE -
x TRUE -2
x FALSE -6
TRUE -2
TRUE -4
TRUE -3
FC 302 Change Conver-
only during sion index
operation
TRUE -
TRUE 0
TRUE -
TRUE 0
Type
Int16
Int16
4 4
Type
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint16
Uint16
Uint16
Uint8
Uint8
Uint8
Uint8
Uint16
Uint16
Uint32
Uint8
Uint8
Int32
Uint32
Uint32
Uint16
Type
Uint8
Uint32
Uint8
Uint32
193
