Parameter Descriptions
5-66 Terminal X30/6 Pulse Output Variable
Select the variable for read-out on terminal X30/6.
This parameter is active when option module MCB 101 is
installed in the frequency converter.
Same options and functions as parameter group 5-6* Pulse
3 3
Outputs.
Option:
[102]
[103]
[104]
[105]
[106]
[107]
[108]
[109]
[119]
5-68 Pulse Output Max Freq #X30/6
Range:
Size related
*
3.7.7 5-7* 24 V Encoder Input
Connect the 24 V encoder to terminal 12 (24 V DC supply),
terminal 32 (Channel A), terminal 33 (Channel B), and
terminal 20 (GND). The digital inputs 32/33 are active for
encoder inputs when [1] 24 V encoder is selected in
1-02 Flux Motor Feedback Source and 7-00 Speed PID
Feedback Source. The encoder used is a dual channel (A
and B) 24 V type. Max input frequency: 110 kHz.
Encoder Connection to the frequency converter
24 V incremental encoder. Max. cable length 5 m.
94
VLT
Function:
Feedback
Motor Current
Torque rel to limit
Torq relate to rated
Power
Speed
Torque
Max Out Freq
Torque % lim
Function:
[0 - 32000 Hz]
MG33MG02 - VLT
®
AutomationDrive Programming Guide
12 13
Illustration 3.39 Encoder Connection
A
B
A
B
Illustration 3.40 Encoder Rotation Direction
5-70 Term 32/33 Pulses Per Revolution
Range:
1024 [1 - 4096 ] Set the encoder pulses per revolution on
*
®
is a registered Danfoss trademark
18 19 27 29 32 33
24V or 10-30V encoder
CW
CCW
Function:
the motor shaft. Read the correct value
from the encoder.
