Parameter Descriptions
5-14 Terminal 32 Digital Input
Option: Function:
Select the function from the available digital
input range.
[0] No operation Functions are described under 5-1* Digital
*
Inputs
5-15 Terminal 33 Digital Input
Option: Function:
Select the function from the available digital
input range and the additional options [60],
[61], [63] and [64]. Counters are used in
Smart Logic Control functions.
[0] No operation Functions are described under 5-1* Digital
*
Inputs
5-16 Terminal X30/2 Digital Input
Option: Function:
[0] No operation This parameter is active when option module
*
MCB 101 is installed in the frequency
converter. Functions are described under
5-1* Digital Inputs
5-17 Terminal X30/3 Digital Input
Option: Function:
[0] No operation This parameter is active when option module
*
MCB 101 is installed in the frequency
converter. Functions are described under
5-1* Digital Inputs
5-18 Terminal X30/4 Digital Input
Option: Function:
[0] No operation This parameter is active when option module
*
MCB 101 is installed in the frequency
converter. Functions are described under
5-1* Digital Inputs
5-19 Terminal 37 Safe Stop
Option: Function:
[1] Safe Stop Coasts frequency converter when safe stop is
Alarm activated. Manual reset from LCP, digital input
or fieldbus.
[3] Safe Stop Coasts frequency converter when safe stop is
Warning activated (T-37 off). When safe stop circuit is
reestablished, the frequency converter will
continue without manual reset.
[4] PTC 1 Alarm Coasts frequency converter when safe stop is
activated. Manual reset from LCP, digital input
or fieldbus. Choice [4] is only available when
the MCB 112 PTC Thermistor Card is
connected.
[5] PTC 1 Coasts frequency converter when safe stop is
Warning activated (T-37 off). When safe stop circuit is
reestablished, the frequency converter will
continue without manual reset, unless a Digital
®
VLT AutomationDrive Programming Guide
5-19 Terminal 37 Safe Stop
Option:
[6] PTC 1 &
[7] PTC 1 &
[8] PTC 1 &
[9] PTC 1 &
Choises [4]-[9] are only available when the MCB 112 PTC
Thermistor Card is connected.
®
MG33MG02 - VLT is a registered Danfoss trademark
Function:
Input set to[80] PTC Card 1 is still enabled.
Choice [5] is only available when the MCB 112
PTC Thermistor Card is connected.
This choice is used when the PTC option is
Relay A gated together with a Stop button through a
Safety relay to T-37. Coasts frequency
converter when safe stop is activated. Manual
reset from LCP, digital input or fieldbus. Choice
[6] is only available when the MCB 112 PTC
Thermistor Card is connected.
This choice is used when the PTC option is
Relay W gated together with a Stop button through a
Safety relay to T-37. Coasts frequency
converter when safe stop is activated (T-37
off). When safe stop circuit is reestablished, the
frequency converter will continue without
manual reset, unless a Digital Input set to [80]
PTC Card 1 is (still) enabled. Choice [7] is only
available when the MCB 112 PTC Thermistor
Card is connected.
This choice makes it possible to use a
Relay A/W combination of Alarm and Warning. Choice [8]
is only available when the MCB 112 PTC
Thermistor Card is connected.
This choice makes it possible to use a
Relay W/A combination of Alarm and Warning. Choice [9]
is only available when the MCB 112 PTC
Thermistor Card is connected.
